Description
The HomeSYS Z-Wave In-Wall Dimmer is an advanced Z-Wave controller perfect for remotely operating your existing light fittings. It allows you to turn your lights ON or OFF and to adjust their level of illumination with a dimming interval of up to 1%. It works with Z-Wave enabled controllers (AUS/NZ version) and can be controlled individually or as part of a group in a pre-configured Scene.
The Z-Wave In-Wall Dimmer Controller is designed to operate inside your wall socket and can be easily installed . The controller is also compatible with many popular BELL PRESS type light fittings including Clipsal IMPRESS and SATURN wall switches.
This product integrates with all Australian certified (921.42MHz) Z-Wave controllers.
The Z-Wave In-Wall Dimmer Controller is a wireless controller which can be a part of many whole-home automation solutions.
- Control the ON/OFF function of your lighting appliances remotely or using a switch
- Control the degree of illumination of your lighting appliances remotely or using a switch
- Acts as a repeater expanding your Z-Wave network
- Wide range of compatibility with existing light fittings and does NOT require expensive cabling
Compatibility:
Incandescent globes, High Voltage Halogens, Low Voltage Halogens with electronic transformers(Trailing Edge and Leading Edge)
CFL globes: Dimmable Philips Tornado CFL lamps and similar products.
LEDs: High performance, energy efficient Starburst LED downlight from Pierlite Australia and similar products.
Generic LEDs will NOT work with this product. If you are unsure please talk to your electrician first.
RF Protocol | Z‐Wave(Multi-Level Command Class) |
RF Frequency | 921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Z‐wave device type | Z-Wave multiple level dimmer, routing slave |
Voltage | AC 230 |
Operation Range | Up to 30m indoor when no obstacles |
Dimming Interval | 1% with safety minimum set up at 25% |
Dimmer Type | Universal, compatible with electronic transformers (Trailing Edge and Leading Edge). Not compatible with iron core transformers. |
Application | Indoor use only |
Operation temperature | 0 ~ 55 °C |
| Max/Min Load | 220W / 75W |
Storage temperature | ‐10 ~ 80 °C |
Weight | 70g |
Housing | ABS |
Compliance | AS/NZS 4268:2008, AS/NZS CISPR 15, IEC60669-2-1 |
Frequency | 50Hz |
Load Compatibility | Incandescent globes, High Voltage Halogens, Low Voltage Halogens with electronic transformers Trailing Edge or Leading Edge type only |
Dimensions | (LxWxH) 45mm x 45mm x 20 mm |
