Description
GOAP modules are “install-and-forget” products. GOAP are made to last, so we only select and use top-quality electronic components. These modules are also the most tested Z-Wave microcontrollers on the market. The Slovenian Institute of Quality and Metrology (SIQ), an independent testing body, tests safety parameters including temperature rise, construction, insulation resistance, power consumption and overload in accordance with the EN 60669-2-1 standard.
GOAP Ltd. is a European company with 26-years experience in the automation field. With their expertise and passion for innovation in automation they have developed a unique, ready to sell, certified and reliable portfolio of 14 Z-Wave wireless Smart Home products under difirent brands and OEM around the world.
All GOAP modules are manufactured in Italy.
RF Protocol | Z-Wave Plus™ , SDK version: 6.51.03 |
RF Frequency | 921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Application | Indoor use only |
Power | 12-24 VDC |
Operation Range | Up to 50m indoors with no obstacles |
Enclosure | Plastic |
Comliance | EN 60669-2-1 |
| Operating Temp. | -10C ~ +50C |
Max. control voltage raitings | -20/+20VDC |
Control signal range | 0-11VDC |
Max. sinking current | 2 mA |
Max. sourcing current | 10 mA |
Dimensions | 41.8 mm x 36.8 mm x 15.4 mm |
