FIBARO Z Wave Double Switch 2

$149.00 incl GST

The Fibaro Z-Wave Double Switch 2 (FIBEFGS-223) is a smart Z-Wave controller capable of remotely operating your existing light fittings. It works with Z-Wave enabled controllers (AUS/NZ version) and can be controlled individually or as part of a group in a pre-configured Scene.

The device is designed to operate inside your wall socket and can be easily installed by a qualified electrician.

The new Fibaro Z-Wave Double Switch 2 (FIBEFGS-223) is a smart Z-Wave wireless module which can control two circuits each with a maximum load of 6.5A per channel and 10A total load per circuit.

  • Control the ON-OFF function of two two independent circuits or appliances remotely or using a wall switch
  • Compatible with all Z-Wave networks
  • Acts as a repeater expanding your Z-Wave network
  • Wide range of compatibility with existing light fittings and does NOT require expensive cabling
  • Latest generation Z-Wave 500 series chip
  • Z-Wave Plus certification
  • Very accurate energy measurement +/- 1 % for power above 5W
  • Supports secure mode (Z-Wave Network Security) encrypted with AES-128

Available on backorder

Category: SKU: DHS-LIT-SWW-FIB-022

Description

This Fibaro Fibaro Z-Wave Double Switch 2 requires 3-wire (including neutral) installation and works with an AC (230V) power supply.

The Fibaro Z-Wave Double Switch 2 also features a secondary switch input which allows it to directly control other associated Z-Wave devices. This means that by turning the switch ON/OFF you can also turn other associated devices ON/OFF even if they are not physically connected to the same Fibaro module. It also enables you to control the local load as part of 2-way and multi-way lighting circuits.

This product integrates with all Australian certified (921.42MHz) Z-Wave controllers including:

  • Raspberry PI with RaZberry Card
  • Fibaro Home Controller 2/Lite
  • DHS Z-Wave Universal Remote Controller
  • DHS Z-Wave Mini Remote Controller

NOTE:

  • No dry contacts – this is important. It means that the new FGS-223 cannot be used to control low voltage systems such as garden lights and irrigation, or where you want a pure volt-free switch such as alarm panels and garage door controls.  If you need device with dry contacts please see zConnect Z-Wave Garage Door Opener or FIBARO Z-Wave Sgl Switch InWall or DHS Z-Wave Sgl Switch InWall



Additional information

Weight50 g
Dimensions42 × 37 × 17 mm
